Abi USB network adapter converter

This USB network adapter is designed to connect two wired networks to a single device with a USB-C port. The adapter features two RJ45 Ethernet ports that can be configured independently, allowing simultaneous connection to different networks. The adapter uses USB 3.1 SuperSpeed (5 Gbps) and supports network speeds of up to 1000 Mb/s per port. Thanks to support for Auto MDI-X, energy-efficient Ethernet, and jumbo frames, the adapter is suitable for demanding network applications. Power is supplied entirely via the USB bus. Applications • Simultaneous connection to two separate networks • Network expansion for laptops and compact systems • Use in server, testing, and management environments Specifications & features • Type: USB network adapter • USB standard: USB 3.1 Gen 1 (SuperSpeed, 5 Gbps) • Connection 1: USB-C male • Connection 2: 2 × RJ45 female (Gigabit Ethernet) • Chipset: Realtek RTL8153 • Network speeds: 10 / 100 / 1000 Mb/s (half- and full-duplex) • Supported standards: IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T) • Additional features: Auto MDI-X, energy-efficient Ethernet (IEEE 802.3az) • Flow control: IEEE 802.3x full-duplex • Jumbo frames: up to 9k • USB compatibility: backward compatible with USB 2.0 • Power supply: USB bus-powered • Status indication: LED for power and network activity • Cable length: approx. 27 cm (incl. connectors) • Color: black System requirements • Operating systems: Windows 7 / 7-64 / 8.1 / 8.1-64 / 10 / 10-64, Linux Kernel 2.6.x or higher, Mac OS 10.9 or higher • Hardware: device with a free USB-C port, Thunderbolt 3 port, USB4 port or Thunderbolt 4 port Ask a product question
