Union pedal SP-600 aluminum, black, 9/16". hang packaging

A bicycle pedal with a die-cast aluminium body, specially designed for use on trekking and mountain bikes.

• The new "lightweight" ball bearing system allows for significant weight and height reductions
• The pedals come with attached and approved retro-reflectors on both sides and a sealed bearing system

• Pedal type
• "Aluminium Pedal" comes with:
• Aluminium body, die-cast, sand-blasted and ED-black coated
• CNC-machined silver finish
• Bearing
• Adjustable and lightweight cone ball bearing system, on both sides
• With 14 x 3/32" bearing balls on each side
• Axle
• Boron steel, heat-treated to 75HRA (+/-3) case hardness
• With 9/16" x 20TPI thread
• Retro-reflectors
• "Snap on" reflectors on both sides
• Approved (BS, JIS, TPP) and according to German StVZO regulations (K369)
• Dimensions
• 102* x 78 x 23 mm (*Length x Width x Height)
• *Length = maximum pedal length when mounted (protruding from the crank)
• Weight
• 272 g/pair
• Standards
• The pedal is designed and produced according to the EN standard
• EN-14766 "Mountain-Bicycles - Safety requirements and test methods"
